MSI MEG Z590 GODLIKE

PROCESSOR

Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron processors 1

Processor socket LGA1200

CHIPSET

Intel Z590 Chipset

MEMORY

4x DDR4 memory slots, support up to 128GB 1

Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR)

Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel CPU (by JEDEC & POR) 1

Max. overclocking frequency:

1DPC 1R Max speed up to 5600 MHz

1DPC 2R Max speed up to 4800+ MHz

2DPC 1R Max speed up to 4400+ MHz

2DPC 2R Max speed up to 4000+ MHz

Supports Dual-Channel mode

Supports non-ECC mode, un-buffered memory

Supports Intel Extreme Memory Profile (XMP)

EXPANSION SLOTS

3x PCIe x16 slots

Support x16/x0/x4, x8/x8/x4, x8/x4+x4/x4, x8+x8/x0/x4, x8+(x4+x4)/x0/x4

PCIE1 & PCI

E2 slots (From CPU)

Support up to PCIe 4.0 for 11th Gen Intel CPU

Support up to PCIe 3.0 for 10th Gen Intel CPU

PCIE3 slot (From Z590 chipset) 1

Supports up to PCIe 3.0

PCI

E3 will run at x1 speed when installing device in M2_4 slot.

MULTI-GPU

Supports 2-Way NVIDIA SLI Technology

Supports 3-Way AMD CrossFire Technology

THUNDERBOLT 4

Intel JHL8540 Thunderbolt 4 Controller

2x Thunderbolt 4 (Type-C) ports on the back panel

Support up to 40 Gbps transfer rate with Thunderbolt devices

Support up to 20 Gbps transfer rate with USB4 devices

Support up to 10Gbps transfer rate with USB 3.2 devices

Support up to 5V/3A , 15W power charging

Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices

Supports up to 8K display (need to connect the DisplayPort of the motherboard or discrete graphics card to the Mini DisplayPort Input port on the
