Aruba Instant On AP22 (RW) Access Point (R4W02A)

Aruba Instant On AP22 (RW) 2x2 Wi-Fi 6 Indoor Access Point
R4W02A

Aruba Instant On AP22 Indoor Access Points deliver affordable, business-grade 802.11ax Wi-Fi for high performance, high density small business environments. Business-grade capabilities are designed to meet the growing number of mobile, IoT, and security needs.
The compact form factor of the Aruba Instant On AP22 Indoor Access Points (AP) delivers multi-user capabilities and a maximum aggregate peak data rate of 1.2 Gbps for high-definition video streaming and cloud application requirements. Everything from mounting hardware to easy-to-use web and mobile app management tools, and business-grade software features are included – no extra charge or need for external controllers.

CERTIFICATIONS
EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments) Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

INPUT VOLTAGE
Power over Ethernet (POE): 802.3af (class 3) DC power (12V) Note: Power sources are sold separately

WI-FI ANTENNA
Integrated down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 4.3dBi in 2.4GHz and 5.6dBi in 5GHz (of the effective, combined pattern for both antennas in each band).

CONNECTIVITY
IEEE 802.11ax

EXTERNAL I/O PORTS
(1) uplink Gigabit Ethernet port, with POE-in support (802.3af)

POWER CONSUMPTION
Max power consumption (worst-case): 10.1W (PoE), 8.8W (DC)

RADIO COVERAGE
Dual Radio for simultaneous dual-band operation 5 GHz 802.11ax 2x2 MIMO for up to 1.2 Gbps wireless data rate,
